KHS PET Bottling line for CSD Beverages

KHS PET Bottling line for CSD Beverages

Available in January 2023. Can be seen in production until then.

Line capacity:
29,500 bph @ 1.5L with Orange Lemonade
34,800 bph @ 1.5 L with Sparkling Water

Status of the line: In operation. Will be available in January 2023
Used for filling: CSD / Water
Cap type: 28 mm, custom design of the factory
Packages: Film only (3×2) Euro 1.200 x 800mm; DüDo 600 x 800mm
Condition: Very good condition, regularly serviced

Consists of:

* KHS Blomax B24C Blow moulding machine, year 2008
– Blow moulds included: No
– Includes preform tipper Mucki MD3, year 2001; silo SBT, overhead conveyor FBT, preform feeder ZVT, horizontal belt RFT, Preform-channel ASTK, Tanner, year 2008, stainless steel execution.

* KHS Innofill DRV-VF-PET Filler/Capper, year 2000
– No. of filling valves: 176, electronical filling system.
– No. of capping heads: 27
– L-R rotation
– Pitch: 102 mm
– Foam cleaning, clean room with full housing.
– Cap feeder Gassner DS600, year 2011, 2 chutes, cascade elevator, sorting feed in closed groove.

* KHS Contimix 65/6/T20 Mixer, year 2001
– Capacity: 65.000 l/h, 6 components
– Brix measurement (Anton Paar), pumps (Hilge).

* KHS Innocheck CUB Cap and fill level control, year 2013
– All-round detection with camera system, pusher in container.

* Videojet Laser date coder, year 2013

* Sacmi Opera 300 RF 26T/R S1/E1 Labeller, year 2012
– Label position: wrap-around, 1 labelling station with label from reel
– 26 bottle plates

* KHS Innocheck CUB Label Control, year 2015
– Light barrier on the carousel of the labeling machine. Pusher in container.

* KHS Kisters Innopack SP060V Shrink packer, year 2001
– Packing: Film only, double lane 3×2
– Capacity: 60 cycles/minute

* KHS Innopack CMS 70/2 Handle applicator, year 2011
– 70 cycles/min., double-track processing
– Laminated handle self-adhesive from the roll, magazines for label strips.

* Schaefer MultiRob-HighS Palletizer, year 2011
– Infeed of packs 2-lane on 1-lane grouping station, loading head as 2-part sliding plate with centering unit.
– Layer inserter with layer stack on scissor lift table, protective fence (Troax).

* 2x Strema A5000BII Pallet wrappers, year 2011
– double head, 2 foil coils, lifting and hold-down device.

* Conveyor systems:
– Air conveyors: included
– Bottle conveyors: included (KHS, plastic chain, rigid railings, dry lubrication)
– Pack conveyors: included (Schaefer, year 2011)
– Pallet conveyors: included (Schaefer, year 2011)
